Main Technical Parameters
| Equipment Outer Dimensions | 1200*1600*2000mm |
| Net Weight | 380KG |
| Power | Steam Heating: 3KW, Electric Heating: 18KW |
| Production Capacity | 30-40 kegs/H |
| Applicable Kegs | Keg with Diameter 250-500mm, Height 360-600mm |
| Tank Heating Way | Electric Heating or Steam Heating |
| Table Board | Fixed |
| Power Supply Voltage | AC 380V 50HZ (customized) |
Main function and feature
1、All procedures are thoroughly controlled by SIEMENS programmable controller. All parameters (time values) can be adjusted and showed through touch screen without stopping the machine
2、Cleaning and filling process can be finished in this machine at one time.
3、All use pneumatic double acting Angle seat valve which could ensure the action sensitivity and reliability.
4、With unique pressure maintaining system，performance stable and reliable, beer loss minimum.
5、With CIP automatic cleaning system.
Working process
Filling station: Fix the keg-keg spear opened–filling–stop—keg spear washed—take the keg
Washing Station: Impact the keg —keg spear opened —Drain residue–water rinse–caustic rinse–hot water rinse–steam sterilization — Co ₂ pressurization — Take the keg.
