500L Beer Fermenter

500L_ Stainless_ Steel_Conical_Beer _Unitank

A 500-liter (L) beer unitank is a vessel used in the brewing industry for both fermentation and conditioning of beer. It’s part of the fermentation cellar equipment and is particularly suitable for smaller-scale breweries, brewpubs, or pilot batches in larger breweries.

Advantage：

Certified stainless-steel material. Sanitary construction with 100% TIG welded joints and seams with sanitary interior polish. All unitanks and jackets inspected and pressure tested to 2 times operating pressure. All unitanks insulated with high efficiency polyurethane foam. We can custom fabricate any tank to meet your brewery’s space and height restrictions. Unitanks design pressure is 30 PSI。

Standard product features:

• Function：Wort Fermentation or maturation
• Unitanksw/ 25% head space.
• Design pressure 30psi or 2
• Interior shell: SUS304, thickness 3mm.
• Exterior shell: SUS304, thickness 2mm.
• Interior and exterior finish bright polish to 2B, hygienic surface.
• 60° conical cone bottom.
• Racking port and discharge port with butterfly valve and fittings.
• Side or Top man way door, shadowless.
• Dimple glycol cooling jackets with glycol inlets and outlets.
• Polyurethane foam insulation, thickness 80mm/>3” on side and bottom.
• Fully welded exterior shell.
• 4 legs with levelling foot pads.
• CIP arm and spray ball.
• Rotating racking arm.
• Vacuum relief at 2bar.
• Pressure relief valve at 30psi as standard.
• Sanitary pressure gauge.
• Perlick style sample valve.
• Unitankscomes with fittings, valves, and all parts.
• Lifting Lugs.
• P100 temperature sensor.
• Carbonation stone.
• Dry hopping port.
• 24V DC liquid solenoid valve.

OPTIONS:

• Additional blow off pipework.
• Larger drain ports.
• Tangential inlets.
• Glycol pipework.
